npi electronic EPMS Housing

The EPMS-07 is a modular system for measuring and/or processing of bioelectrical signals in electrophysiology and the application of substances in pharmacology.

npi electronic EPMS Housing

The system is housed in a 19" rackmount cabinet (3U) containing a power supply and has room for up to 7 plug-in units depending on the width of a module.

Modules can have a width of 1, 1.5, 2 or 3. The width of the modules in detail is given in the "Options" field for each module. The sum for one 19" cabinet must not exceed seven.

Accessories

EPMS-H-07

In addition to the standard power supply of the EPMS-07, the EPMS-H-07 has a built-in high voltage power supply. This is necessary for all MVCS / MVCC modules, the HVA-100, HV-TR150 and HVC-03M modules. The output voltage depends on the modules in use.

EPMS-E-07

Is used with an external power supply (PWR-03D, to be ordered separately).

EPMS-03

The EPMS-03 is a modular system for measuring and/or processing of bioelectrical signals in electrophysiology and the application of substances in pharmacology. The system is housed in a housing containing a power supply and has room for up to 3 plug-in units depending on the width of a module.The plug-in units are connected to mains by a bus at the rear panel.

Dimensions
Dimensions
19” rackmount cabinet, for up to 7 plug-in units
133.4 mm (3U) high (1U=1 3/4” = 44.45 mm), 302 mm deep
EPMS-07
EPMS-07
Power supply: 115/230 Volts AC, 60/50 Hz, fuse 2/1 A slow, 45-60 W (depending on the modules plugged in)
EPMS-E-07
EPMS-E-07
External power supply (for EPMS-E): 115/230 Volts AC, 60/50 Hz, fuse 1.6/0.8 A, slow
Dimensions of External power supply: (W x D x H) 225 mm x 210 mm x 85 mm
EPMS-03
EPMS-03
Desktop cabinet, for up to 3 plug-in units
Power supply: 115/230 Volts AC, 60/50 Hz, fuse 0.8 A / 0.4 A slow
Maximum current supply: 500 mA
Dimensions: 3U high (1U=1 3/4” = 44.45 mm), 254 mm deep, 265 mm wide
